InstaFloor 30mm Adhesive Free Interlocking Gym Tile

Easy Clean Surface | 500 x 500 x 30mm | Vertical Connectors included

A complete adhesive free gym floor solution which combines stunning aesthetics with a premium easy clean, highly shock proof surface.

Suitable for free weights, weight lifting and cross-fit areas. The GT30 Rubber tile system provides high performance shock absorption to prevent injuries to athletes and protects subfloors when lifting weights. Impact sound insulation is also increased, preventing transmission through the building structure and creating a quieter environment.

For bulk orders and larger gym projects please contact us for a custom quote.

Usage	Free weights, weightlifting, cross-fit areas.
Thickness	30mm
Tile Size	500x500mm
Top surface	Premium, smooth, easy clean
Tiles required per meter square	4
Connectors	Plastic connectors (provided free of charge)
Colour	Black with EPDM Flecks
Base	Cone shaped profile
Density	Approx. 900kg/m3
Acoustic Performance	ΔL (C ) = 23 dB Lnn,r,w (C ) = 55 dB
Quality Assurance	ISO9001 ISO1401
Warranty	15 Years

Image below shows the straight ramp and corner ramp options available. These are black to match with any colour main tile selected. The straight ramps are 1000x250mm with the corner ramps 500/500x250mm. Both interlock with the provided connectors for a secure freestanding gym floor solution.

Part of a complete adhesive free gym flooring system that can be combined with the following options; Please contact us for details

InstaFloor 1000x1000x30mm Artificial grass tiles
InstaFloor Prowler Track with markings
InstaFloor Ramp Tiles (Straight and Corner options)

The product is supplied with 12 interlocking plates per square meter to connect the tiles together without the need for adhesives.

Light Grey Fleck 30mm Flooring with ramp tiles and wooden lifting insert

Artificial grass tiles in Black, Green and Blue are available and interlock perfectly into this solution.

Numbered prowler tracks are also available on special order. Please contact us for more information.

All tiles are designed to lock together to provide a step-less transition between gym areas. This includes the tiles, ramps and grass sections.

Underneath of INSTA 30mm Interlocking tiles showing connecting plates

Rubber Flooring Technology

Reduces impact noise and vibration from gym equipment
Prevents impact sound transferring into the building structure.
Reduces noise complaints.
Creates a safe exercise platform for users that reduces fatigue and injuries.
Healthy anti-microbial flooring surface.
Prevents damage to sub floor.
Provides high level of shock absorption.
Enhances the aesthetics of the internal space used for exercise

How to create a completely free-standing gym floor using the interlocking ramp tiles

Size of Freestanding area	Area of workout area	500x500mm tiles required	Straight Ramps Required	Corner Ramps Required
3 x 3 Grid	2.25 sqm / 1500 x 1500 mm	9	4	4
4 x 4 Grid	4 sqm / 2000 x 2000 mm	16	6	4
5 x 5 Grid	6.25 sqm / 2500 x 2500 mm	25	8	4
6 x 6 Grid	9 sqm / 3000 x 3000 mm	36	10	4

How to create a 2 wall corner free-standing gym floor using the interlocking ramp tiles

Size of Freestanding area	Area of workout area	500 x 500 mm tiles required	Straight Ramps Required	Corner Ramps Required
3 x 3 Grid	2.25 sqm / 1500 x 1500 mm	9	3	1
4 x 4 Grid	4 sqm / 2000 x 2000 mm	16	4	1
5 x 5 Grid	6.25 sqm / 2500 x 2500 mm	25	5	1
6 x 6 Grid	9 sqm / 3000 x 3000 mm	36	6	1

Why InstaFloor?

InstaFloor provides a high-performance range of rubber gym flooring that is suitable for weightlifting areas, commercial gyms, strength and conditioning areas and fitness studios. In addition, we are committed to helping health clubs and gym facility owners to find solutions to acoustic noise issues associated with the low frequencies of sound and vibration created by gym equipment. This is vitally important as a growing number of gym and fitness facilities are now created on upper floors within residential and commercial buildings, and preventing impact sound has become a major concern.

All InstaFloor rubber gym flooring is made from recycled rubber from used vehicle tyres, preventing these materials going into landfill, and creating a fully recyclable product which is kind to the environment.

Is all rubber gym flooring the same? No
The manufacturing processes and quality of rubber granules will significantly
affect the final aesthetic presentation and durability of the rubber gym flooring.
InstaFloor, under quality management ISO9001 and ISO14001 controls, provide
high quality recycled rubber gym flooring you can trust.
